Face Extraction API with Flask and DeepFace

Description

A simple Flask-based API that extracts the face with the highest confidence score from an image, expands its bounding box by 20%, and returns the cropped face as a downloadable JPEG file, without persisting it on the server. The API supports two methods for image input: providing an image URL or uploading an image file directly.

Features

• Image URL Input: Supports processing images by downloading them from a provided URL.
• File Upload: Accepts image files uploaded directly via a multipart/form-data POST request.
• Utilizes the DeepFace library, specifically the Yunet detector, for face detection.
• Automatically selects the face detected with the highest confidence score.
• Enlarges the bounding box of the detected face by 20% to ensure complete capture.
• Provides the cropped face image as a downloadable JPEG attachment.
• Minio Integration: Features optional endpoints for uploading the extracted face (or the original image with the detected face highlighted) directly to a Minio object storage server.

Example

The following demonstrates the original image and the cropped face image side by side:

Requirements

• Python 3.9+
• Docker (optional, for containerized deployment)

Installation and Running Locally

1. Clone this repository to your local machine:

   git clone https://github.com/neozhu/face-extraction-api.git
   # Replace with your fork if necessary
   cd face-extraction-api


2. Install the required Python dependencies:

   pip install -r requirements.txt


3. Create a .env file in the project’s root directory and populate it with your Minio server configuration details, similar to the example below:

   # Example .env Configuration
   MINIO_ENDPOINT=minio.example.com
   MINIO_ACCESS_KEY=YOUR_MINIO_ACCESS_KEY
   MINIO_SECRET_KEY=YOUR_MINIO_SECRET_KEY
   MINIO_BUCKET_NAME=your-target-bucket


   Ensure you replace placeholder values with your actual Minio credentials and endpoint.

4. Run the Flask application:

   python app.py


The API will then be available at http://localhost:5000.

Running with Docker

1. Build the Docker image:

   docker build -t face-extraction-api .


2. Run the Docker container, mapping port 5000:

   docker run -p 5000:5000 face-extraction-api


   (Ensure your .env file is accessible to Docker if not using build arguments for secrets.)

3. Example Docker Compose configuration:

version: '3.8'
services:
  face-extraction-api:
    image: blazordevlab/face-extraction-api:latest
    container_name: faceextraction
    ports:
      - "5000:5000"
    labels:
      - "traefik.enable=true"
      # Replace 'faceextraction.example.com' with your actual domain
      - "traefik.http.routers.faceextraction.rule=Host(`faceextraction.example.com`)"
      - "traefik.http.routers.faceextraction.tls=true"
      - "traefik.http.routers.faceextraction.entrypoints=https"
      - "traefik.http.services.faceextraction.loadbalancer.server.port=5000"
      - "traefik.docker.network=proxy"
    networks:
      proxy:
    security_opt:
      - no-new-privileges:true
networks:
   proxy:
      external: true

API Endpoints

1. Extract Face by Image URL

• Endpoint: /extract_face

• Method: POST

• Request Payload: JSON object containing the image_url key.

  Example JSON Payload:

  {
    "image_url": "https://example.com/path/to/your_image.jpg"
  }


• Success Response: Returns the cropped face image as a downloadable JPEG file (image/jpeg).

2. Extract Face by File Upload

• Endpoint: /upload_extract_face

• Method: POST

• Request Payload: multipart/form-data with an image file in the file field.

  Example using curl:

  curl -X POST -F "file=@/path/to/your_image.jpg" http://localhost:5000/upload_extract_face --output extracted_face.jpg


• Success Response: Returns the cropped face image as a downloadable JPEG file (image/jpeg).

3. Extract Face from Image URL and Upload to Minio

• Endpoint: /extract_face_to_minio

• Method: POST

• Request Payload: JSON object containing the image_url key.

  Example JSON Payload:

  {
    "image_url": "https://example.com/path/to/your_image.jpg"
  }


• Success Response: JSON object with:

  • status (string): Operation status (e.g., “success”).
  • message (string): Confirmation message indicating successful extraction and upload.
  • url (string): The full URL of the uploaded cropped face image in Minio.
  • source_type (string): Indicates if the source image URL was from the Minio server itself (“minio”) or an external location (“external”).

4. Upload Image, Extract Face, and Upload Both to Minio

• Endpoint: /upload_face_to_minio

• Method: POST

• Request Payload: multipart/form-data with:

  • An image file in the file field.
  • A path parameter (string, optional) specifying the target directory in Minio for the original image.

  Example using curl:

  curl -X POST -F "file=@/path/to/your_image.jpg" -F "path=uploads/test_images" http://localhost:5000/upload_face_to_minio


• Success Response: JSON object with:

  • status (string): Operation status.
  • message (string): Confirmation of successful upload to Minio.
  • storage_destination (string): Confirms the file was uploaded to Minio.
  • original_url (string): The full URL of the original uploaded image in Minio.
  • face_image_url (string): The full URL of the cropped face image, typically saved under a faces/ subdirectory relative to the original image path in Minio.

License

This project is licensed under the MIT License.
